Send InquirySemi Automatic Tile Adhesive Making Plant
Semi Automatic Tile Adhesive Making Plant Specification
- Phase
- 3
- Shape
- U Shape
- Product Type
- semi automatic tile adhesive making plant
- General Use
- making tile adhesive
- Material
- Steel Alloy
- Capacity
- 1 Ton
- Weight (kg)
- 1300 Kilograms (kg)
- Computerized
- No
- Automatic
- No
- Touch Screen
- No
- Control System
- Other
- Surface Treatment
- Other
- QC System
- yes
- Voltage
- 440 Volt (v)
- Feature
- High Efficiency, Simple Control, Stable Operation, Low Noise, High Performance, Lower Energy Consumption
- Color
- grey
- Warranty
- 1 year
Semi Automatic Tile Adhesive Making Plant Trade Information
- Minimum Order Quantity
- 1 Unit
- FOB Port
- india
- Payment Terms
- Cash Advance (CA), Cash in Advance (CID)
- Supply Ability
- 15 Units Per Month
- Delivery Time
- 15 Days
- Sample Available
- Yes
- Packaging Details
- Standard Packing
- Main Domestic Market
- All India
About Semi Automatic Tile Adhesive Making Plant
Semi-Automatic Tile Adhesive Manufacturing Plant
Technical Specification
| Parameter | Specification |
|---|---|
| Plant Type | Semi-Automatic Dry Mix Mortar / Tile Adhesive Plant |
| Production Capacity | 310 TPH (Tons Per Hour) |
| Daily Production | 2080 Tons/Day |
| Mixer Type | Ribbon Blender / Twin Shaft Paddle Mixer |
| Mixer Capacity | 10002000 kg per batch |
| Batch Cycle Time | 1015 Minutes |
| Mixing Uniformity | CV 5% |
| Automation Grade | Semi-Automatic |
| Installed Power | 2550 HP (depending on capacity) |
| Power Supply | 415V, 50Hz, 3 Phase |
| Raw Material Feeding | Manual / Screw Conveyor |
| Additive Feeding | Manual Weighing System |
| Finished Product Discharge | Pneumatic Gate |
| Packing Machine | Semi-Automatic Valve Bag Filling Machine |
| Packing Capacity | 58 Bags/Minute (2050 kg bags) |
| Dust Collection System | Bag Filter Type |
| Air Compressor | 57.5 HP |
| Plant Structure | Mild Steel (MS) Fabricated |
| Surface Finish | Industrial Paint Coating |
| Manpower Requirement | 35 Operators |
| Plant Area Required | 5001000 sq.ft |
| Plant Height | 610 m |
| Control Panel | Push Button / PLC Optional |
Main Equipment Included
- Raw Material Hopper
- Screw Conveyor
- Ribbon Blender / Paddle Mixer
- Additive Feeding Hopper
- Finished Product Storage Hopper
- Valve Bag Packing Machine
- Dust Collector
- Air Compressor
- Electrical Control Panel
Raw Materials for Tile Adhesive
- Ordinary Portland Cement (OPC 43/53 Grade)
- Washed Silica Sand (100300 Mesh)
- Redispersible Polymer Powder (RDP)
- Hydroxy Propyl Methyl Cellulose (HPMC)
- Calcium Formate
- Other Performance Additives
Typical Product Range
- C1 Tile Adhesive
- C2 Tile Adhesive
- Heavy Duty Tile Adhesive
- Stone Adhesive
- Floor Tile Adhesive
- Wall Tile Adhesive
